| Usage: | Chemical | Application: | Oil, Industrial Alcohol, Alkali, Acid, Industrial Wastewater, Water |
|---|---|---|---|
| Capacity: | 1000Litre | Shape: | Square |
| Product Name: | Functional Chemical Container | Size: | L1150*W950*H1000 |
| The Thickness Of The Inner Container: | 3-5mm | Namer: | IBC Container |
| High Light: | HDPE White IBC Tank,1000L White IBC Tank |
||
L1150*W950*H1000 HDPE White IBC Tank Functional Chemical Storage
Specifications:
| Entirety Description | |
| Size | L1200*W1000*H1150mm |
| Capacity | 1000L |
| Unit weight | 58±3(KG) |
| Inner container description | |
| Size | L1150*W950*H1000 |
| Material | HDPE(Virgin material available) |
| Colour | White or Blue. |
| The thickness of the inner container | 3-5mm |
| External description | |
| Material | Malleable hot-dip galvanized steel pipe |
| Screw | 8.8 Galvanized anti-skid screw |
| Thickness | 1.0-2.0 |
Description:
HDPE1000L IBC, are widely applicable for packaging and transporting all kinds of liquids, dope, and powder, and has been offered a UN certificate.
Technical data:
Nominal Capacity: 1000L
Brimful Capacity: 1050L
Length :1200mm
Width:1000mm
Height with pallet:1150mm
Dia. Of Filling opening:140mm
Dia. Of Dischage opening:50mm
Height of Fork opening:100mm
Lable plate:1-2 pcs
Corner Protector: 4 pcs
Weight of Inner container:18±1KG
Total approx:60kg±2kg
Advantage:
Chemical IBCs are transportable bulk containers that are used to store large quantities of hazardous liquids.
Due to the rectangular design of the IBC, this type of chemical container has a larger capacity than a drum. It’s also much easier to stack and transport due to its angular design.
Rigid IBCs are constructed from a hard, durable plastic and feature a metal outer cage that protects the plastic chemical container. They are often used across a range of operations including construction, manufacturing, mining and agriculture.
Feature
Global supply, global standard design, standard mechanical equipment easy to load and unload.
IBCs are stacked with each other, which can be reused and save costs.
There are many options of assembled design structure, easy to maintain and repair.
UN certification.
High cost performance, suitable for shipping containers and inland transportation, saving packaging
Cost of transportation and storage.
Pipe frame: the steel pipe surface is coated with patented technology, with high vibration and impact resistance, and has passed the inspection of European authorities.
Tray: steel tray/steel-plastic composite tray
Content container: It is made of UV-resistant high-density polyethylene blow molding at one time, and the top inlet is equipped with a top cover, including a pressure ventilation device and a sealing ring.
